Flexible SAFF Media
Flexible SAFF (Submerged Aerated Fixed Film) Media is used in aerobic biological treatment
processes to support microbial growth and improve organic load removal.
General Information
| Field |
Value |
| Product |
Bio Media / Saff Media |
| Design |
D-27F (FB 10.27) |
| Color |
Zed Black |
| Flute Height |
27 mm (±5%) |
Dimensions
| Parameter |
Value |
| Length |
1200 mm (±10%) |
| Width |
600 mm (±10%) |
Thickness Options:
| Thickness (mm) |
Micron |
Tolerance |
| 0.30 |
300 |
±10% |
| 0.40 |
400 |
±10% |
| 0.50 |
500 |
±10% |
Surface & Features :
| Field |
Value |
| Other Key Features |
Double Edged Folding, Virgin PVC Film, UV Resistance Sheet |
| Surface Area |
95 to 105 Sq. Meter / 1 Cubic Meter = 51 Sheets |
| Other Details |
Solvents provided with order. Low K value grade PVC resin used, mostly from Reliance
Industries or Formosa (Imported). |
| Solvents |
Pure Cyclohexanone (GSFC) Grade and Imported |
Composition Material :
| Material / Test |
Specification |
| PVC Resin |
K-57 Low Grade |
| Thickness Standard |
IS 2508 (Followed) |
| Density Test |
ASTM D 792 |
| Width |
600 mm |
| Fire Retardant Test |
ASTM D 635 |
| Sr NO |
FEATURES |
DESCRIPTION |
| 1 |
FORM |
Sheet and Module |
| 2 |
SPECIFIC SURFACE AREA |
102 |
| 3 |
VOID RATIO |
>97 |
| 4 |
FLUTE TYPE |
Both Sheet Cross Flute |
| 5 |
CROSS FLUTE SIZE |
27 mm |
| 6 |
THICKNESS |
0.3 mm, 0.4 mm, 0.5 mm, or as per requirement |
| 7 |
DIMENSION |
1200 × 600 × 600 mm - Module (Tolerance: ±50 mm)
1200 × 600 mm - Sheet (Tolerance: ±10 mm)
|
| 8 |
MOC |
PVC |
| 9 |
APPLICATION |
Have higher surface area, this media is very useful for Saff reactors,
Trickling Filters, Anaerobic Digesters
|
